Technical Specification
Illumination: Transmission: D/0 (diffuse illumination, 0° Viewing); Approximately CIE15 stipulates 0/0 (parallel light illumination/0 degree reception); Comply with standards: ASTM D1003/1044, CIE No.15, GB/T 3978, GB 2893, GB/T 18833, ASTM E308, DIN5033 Teil7
Characteristic: The national standard pharmacopoeia color measurement, glass processing, plastic processing, film, display screen processing, packaging industry, liquid medicine analysis and other industries are widely used in color analysis and transmittance testing, supporting trace transmittance measurement.
Integrating sphere size: Φ 40 mm
Light source: Combined full spectrum LED light source
Spectral method : Plat grating spectrometer
Sensor : Silicon photodiode array (dual row 40 groups)
Wavelength range: 360 ~780 nm
Wavelength interval: 10nm
Transmittance range: 0~200%
Measuring aperture: Transmission: Φ 10 mm
Color Space : CIE LAB, XYZ, Yxy, LCh, CIE LUV, Musell, s-RGB, HunterLab, βxy, DIN Lab99 ,CMYK
Color difference formula: ΔE*ab,ΔE*uv,ΔE*94,ΔE*cmc(2:1),ΔE*cmc(1:1),ΔE*00, DINΔE99,ΔE(Hunter),ΔE*CH
Observer Angle: 2°/10°
Measuring time: Fast mode: about 0.8s
Operating temperature range: 0~40°C (32~104°F)
Displayed Data: Spectrum/values, sample chromaticity value, color difference value/graph, chromaticity diagram, color simulation, pass/fail results, color offset
Illuminant Life Span: More than 3 million measurements in 5 years
Dimensions : Length x width x height = 370 x 300 x 200 mm
Weight : About 9.6kg
